Product Features
Six-sided Uniform Heating SystemEquipped with dual heating modules and six-side heating design. The silicone rubber heating wire wrapped with aluminum foil ensures fast temperature rise speed and excellent overall temperature uniformity inside the cavity.
Patented HermeSEAL® Encapsulation TechnologyAdopts patented encapsulated infrared assembly design, which resists high temperature, high humidity and corrosive working environments. It maintains long-term stable sensing performance even in harsh experimental conditions.
Item | BJPX-C50D | BJPX-C80D | BJPX-C160D | BJPX-C180D | BJPX-C220D | BJPX-C300D |
Type | Dry heat series, air jacket |
|
|
|
|
|
Sterilization Type | 180℃ dry heat sterilization |
|
|
|
|
|
Capacity | 50L | 80L | 160L | 180L | 220L | 300L |
Temperature Sensor | PT100 |
|
|
|
|
|
Temperature Range | RT+5~60℃ |
|
|
|
|
|
Temperature Fluctuation | ±0.5℃ (@37℃: ±0.3℃) |
|
|
|
|
|
Temperature Uniformity | ±1.0℃ (@37℃: ±0.5℃) |
|
|
|
|
|
Temperature Precision | 0.1℃ |
|
|
|
|
|
Timing Range | 0~999h or continuous |
|
|
|
|
|
Display | 7-inch touch screen |
|
|
|
|
|
CO2 Control Mode | IR infrared sensor with calibration certificate |
|
|
|
|
|
CO2 Concentration Range | 0~20vol% |
|
|
|
|
|
CO2 Uniformity | 0.2vol% |
|
|
|
|
|
CO2 Control Resolution | 0.1vol% |
|
|
|
|
|
Ambient Requirements | Ambient temperature: 18~30℃ (Recommended: 25±2℃); Ambient humidity: ≤80% |
|
|
|
|
|
Filter Configuration | CO2 gas filter |
|
|
|
|
|
Power Supply | AC 220V, 50/60Hz (Standard); 110V, 50/60Hz (Optional with external transformer); Wiring method: plug |
|
|
|
|
|
Power Consumption | 1400W | 1700W | 2400W | 2400W | 2400W | 2400W |
Shelves | 2pcs, adjustable |
|
|
|
|
|
Standard Accessories | Shelves, USB interface, CO2 relief valve, water tank, CO2 gas filter |
|
|
|
|
|
Optional Accessories | Three-way connector |
|
|
|
|
|
Internal Dimension (W*D*H) | 332*326*496mm | 401*352*576mm | 551*462*646mm | 451*506*716mm | 502*545*786mm | 534*565*996mm |
External Dimension (W*D*H) | 660*552*764mm | 688*622*850mm | 870*710*958mm | 770*722*992mm | 820*762*1060mm | 860*802*1260mm |
Package Size (W*D*H) | 730*642*784mm | 758*712*870mm | 940*800*978mm | 840*812*1012mm | 890*852*1260mm | 930*892*1460mm |
Net Weight | 80kg | 90kg | 115kg | 125kg | 137kg | 169.5kg |
Gross Weight | 95kg | 105kg | 130kg | 140kg | 152kg | 184.5kg |
